System
|
|
Main Processor
|
Embedded processor
|
|
Internet Protocol
|
P2P; IPv4; DNS; DDNS; TCP; UDP
|
|
Interoperability
|
ONVIF; CGI
|
|
SDK and API
|
Yes
|
|
Basic
|
|
Product Type
|
Controller
|
|
Buzzer
|
Yes
|
|
Casing Material
|
PC + ABS
|
|
Function
|
|
Unlock Mode
|
Card; remote; password; fingerprint; Bluetooth; combination unlock
|
|
Period List
|
128 periods
|
|
Holiday Period
|
128 periods
|
|
Network Update
|
Yes
|
|
Blocklist/Allowlist
|
Yes
|
|
Peripheral Card Reader
|
Supports 2 × RS-485 card readers; 2 × Wiegand card readers
|
|
Multi-user Authentication
|
Yes (Use with platform)
|
|
Real-time Monitoring
|
Yes
|
|
Multi-factor Authentication
|
Yes
|
|
Web Configuration
|
Yes
|
|
User
|
|
User (Card) Type
|
General user, VIP user, guest user, patrol user, blocklist user, and other users
|
|
Capacity
|
|
User Capacity
|
1,000 (main control mode), 10,000 (sub control mode)
|
|
Fingerprint Capacity
|
3,000
|
|
Card Capacity
|
5,000 (main control mode), 50,000 (sub control mode)
|
|
Bluetooth Card Capacity
|
5,000
|
|
Record Capacity
|
300,000
|
|
Port
|
|
RS-485
|
3
|
|
Wiegand
|
2 × input
|
|
Network Port
|
1 × RJ-45 10/100 Mbps Ethernet port
|
|
Alarm Input
|
2 (digital quantity)
|
|
Alarm Output
|
2 (digital quantity)
|
|
Alarm Linkage
|
Yes
|
|
Exit Button
|
2
|
|
Door Status Detection
|
2
|
|
Lock Control
|
2
|
|
Alarm
|
|
Tamper Alarm
|
Yes
|
|
Duress Alarm
|
Yes
|
|
Door Sensor Timeout
|
Yes
|
|
Intrusion
|
Yes
|
|
Illegal Card Exceeding Threshold
|
Yes
|
|
Duress Fingerprint
|
Yes
|
|
General
|
|
Power Supply
|
Power in: 12V DC or Power over Ethernet IEEE 802.3at Type 2 Class 4
|
|
Protection
|
IK06
|
|
Power Consumption
|
Standby Power (no peripheral devices):
≤2 W
Working Power:
Total power budget if powered by DC: 1700 mA at 12 V for peripheral devices (locks, readers etc.)
Total power budget if powered by PoE: 1200 mA at 12 V for peripheral devices (locks, readers etc.)
|
|
Product Dimensions
|
186.4 mm × 185.8 mm × 58.3mm (7.34" × 7.31" × 2.30") (L × W × H)
|
|
Packaging Dimensions
|
254 mm × 243 mm × 86 mm (10.00" × 9.57" × 3.39") (L × W × H)
|
|
Operating Temperature
|
–10 °C to +55 °C (+14 °F to 131 °F)
|
|
Operating Humidity
|
5%–95% (RH), non-condensing
|
|
Operating Environment
|
Indoor
|
|
Gross Weight
|
0.99 kg (2.18 lb)
|
|
Installation
|
Surface Mount; Guide Rail Mount
|
|
Certifications
|
CE; FCC; UL
|
