System
|
|
Main Processor
|
Industrial-grade processor
|
|
Operating System
|
Embedded Linux
|
|
Operating Interface
|
Web, Local GUI
|
|
AI
|
|
AI by Recorder
|
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus
|
|
AI by Camera
|
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; object monitoring
|
|
AcuPick AI by Camera + Recorder
|
Max. 64-channel, 1 combined event per channel/s
|
|
Perimeter Protection
|
|
Perimeter Performance AI by Recorder (Number of Channels)
|
Simultaneous mode: 32 channels, 10 IVS rules for each channel Heterogeneous mode: 24 channels, 10 IVS rules for each channel
|
|
Perimeter Performance of AI by Camera (Number of Channels)
|
64 channels
|
|
Face Detection
|
|
Face Attributes
|
Gender; age group; glasses; expressions; face mask; beard
|
|
Face Detection Performance of AI by Recorder (Number of Channels)
|
Simultaneous mode: 8 channels (up to 12 face images/s each channel) Heterogeneous mode: 5 channels (up to 12 face images/s each channel)
|
|
Face Detection Performance of AI by Camera (Number of Channels)
|
64 channels
|
|
Face Recognition
|
|
Face Database Capacity
|
Up to 40 face databases with 300,000 images, with a total capacity of 48 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
|
|
Face Recognition Performance of AI by Recorder (Number of Channels)
|
Simultaneous mode: 32-channel FD (by camera) + FR (by recorder),image stream: 32 face images/s; 8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder),image stream: 16 face images/s; 5-channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s
|
|
Face Recognition Performance of AI by Camera (Number of Channels)
|
64 channels
|
|
SMD Plus
|
|
SMD Plus by Recorder
|
32-channel: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
|
|
SMD Plus by Camera
|
64 channels
|
|
Video Metadata
|
|
Metadata Performance of AI by Recorder (Number of Channels)
|
8 channels
|
|
Metadata Performance of AI by Camera (Number of Channels)
|
64 channels
|
|
People Attributes
|
9 human body attributes
|
|
Human Attributes
|
Top color, top type, hat, bag, age, gender and umbrella
|
|
Motor Vehicle Attributes
|
License plate, plate color, vehicle model, vehicle logo, plate color, ornament, calling,
|
|
Non-motor Vehicle Attributes
|
Vehicle model, vehicle color, number of persons, helmet.
|
|
Vehicle License Plate Comparison
|
|
ANPR by Camera (Number of Channels)
|
64 channels
|
|
License Plate Database Capacity
|
Blocklist and allowlist: 20,000
|
|
Audio and Video
|
|
Access Channel
|
128 channels
|
|
Network Bandwidth
|
AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing
|
|
Resolution
|
32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1
|
|
Decoding Capability
|
AI disabled: 2-channel 32 MP@30 fps; 2-channel 24 MP@30 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps；128-channel D1@30 fps AI enabled: 1-channel 32 MP@30 fps; 1-channel 24 MP@30 fps; 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps； 80-channel D1@30 fps
|
|
Video Output
|
2 VGA, 4 HDMI; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode: max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1 and HDMI2 is 4K; max. resolution of HDMI3 is 8K; max. resolution of HDMI4 is 1080p Heterogeneous mode: Simultaneous video source output for VGA1 and HDMI1, simultaneous video source output for VGA2 and HDMI2. Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1, HDMI2 and HDMI3 is 4K; max. resolution of HDMI4 is 1080p
|
|
Multi-screen Display
|
Main screen: 1/4/8/9/16/25/36/64 Sub screen: 1/4/8/9/16/25/36
|
|
Third-party Camera Access
|
ONVIF; RTSP; Sony; Axis; Arecont; Pelco; Canon; Samsung
|
|
Compression Standard
|
|
Video Compression
|
Smart H.265+; H.265; Smart H.264+; H.264; MPEG4; MJPEG
|
|
Audio Compression
|
G.711a; G.711u; PCM; G726
|
|
Network
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; ISCSI
|
|
Mobile Phone Access
|
iOS; Android
|
|
Interoperability
|
ONVIF (Profile S/profile T/Profile G); CGI; SDK
|
|
Browser
|
Chrome IE 9 or later Firefox
|
|
Network Mode
|
Multi-address mode, load balance, fault tolerance and other network port binding modes
|
|
Recording Playback
|
|
Multi-channel Playback
|
Up to 16 channels
|
|
Record Mode
|
Manual; alarm; motion detection; scheduled
|
|
Backup Method
|
Portable hard drive, eSATA disk, burner, USB device and network
|
|
Playback Mode
|
1. Play, pause, stop, fast forward, fast backward, rewind, play by frame 2. Full screen, backup (cut/file), partially enlarge, audio on/off
|
|
Storage
|
|
Disk Group
|
Yes
|
|
RAID
|
RAID 0/1/5/6/10
|
|
Hot Swapping
|
Yes
|
|
Alarm
|
|
General Alarm
|
Motion detection; video tampering; video loss; scene changing, PIR alarm, IPC external alarm
|
|
Anomaly Alarm
|
Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan
|
|
Intelligent Alarm
|
Face detection; face recognition; perimeter protection (intrusion and tripwire); SMD Plus alarms; ANPR; people counting; stereo analysis; crowd distribution; heat map
|
|
Alarm Linkage
|
Record; snapshot; IPC external alarm output; buzzer; log, preset; email
|
|
Port
|
|
Audio Input
|
1-channel RCA
|
|
Audio Output
|
2-channel RCA
|
|
Alarm Input
|
16 channels
|
|
Alarm Output
|
8 channels
|
|
HDD Interface
|
8 SATA ports, up to 16 TB. The maximum HDD capacity varies with environment temperature.
|
|
eSATA
|
1
|
|
RS-232
|
1
|
|
RS-485
|
1 × A/B
|
|
USB
|
4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports)
|
|
HDMI
|
4
|
|
VGA
|
2
|
|
Network Port
|
2 (10/100/1000/2500 Mbps Ethernet port, RJ-45)
|
|
General
|
|
Power Supply
|
100–240 VAC, 50/60 Hz
|
|
Power Consumption
|
<18 W (without HDD)
|
|
Net Weight
|
6.40 kg (14.11 lb) (without HDD)
|
|
Gross Weight
|
8.59 kg (18.94 lb) (without HDD)
|
|
Product Dimensions
|
440.0 mm × 458.4 mm x 94.9 mm (17.32" × 18.05" × 3.57") (W × D × H)
|
|
Packaging Dimensions
|
571.0 mm × 499.0 mm × 211.0 mm (22.48" × 19.65" × 8.31")(W × D × H)
|
|
Operating Temperature
|
–10 °C to +55 °C (14 °F to +131 °F)
|
|
Storage Temperature
|
0 °C to +40 °C (+32 °F to +104 °F)
|
|
Operating Humidity
|
10%–93% (RH), non-condensing
|
|
Installation
|
Rack or desktop
|
|
Certifications
|
FCC: 47 CFR FCC Part15, SubpartB, Class A CE-EMC: EN 55032:2020, Class A; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55024:2010+A1:2015; EN 55035:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014+A11:2017
|
