Camera
|
|
Image Sensor
|
Panoramic: 1/1.8" CMOS
Detail: 1/2.8" CMOS
|
|
Pixel
|
Panoramic: 4 MP
Detail: 4 MP
|
|
Max. Resolution
|
Panoramic: 2560 (H) × 1440 (V)
Detail: 2560 (H) × 1440 (V)
|
|
ROM
|
Panoramic: 4 GB
Detail: 256 MB
|
|
RAM
|
Panoramic: 1 GB
Detail: 1 GB
|
|
Electronic Shutter Speed
|
Panoramic: 1/1 s–1/30,000 s
Detail: 1/1 s–1/30,000 s
|
|
Scanning System
|
Progressive Scanning
|
|
Min. Illumination
|
Panoramic:
Color: 0.001 lux@F1.0
B/W: 0.0001 lux@F1.0
0 lux (white light on)
Detail:
Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux (IR light on)
|
|
Illumination Distance
|
30 m (98.44 ft) (white light)
150 m (49.13 ft) (IR)
|
|
Illuminator On/Off Control
|
Zoom Prio; manual; auto; off
|
|
Illuminator Number
|
Panoramic: 4x white light
Detail: 2x white light; 4x IR
|
|
Lens
|
|
Focal Length
|
Panoramic: 4 mm
Detail: 4.8 mm–115 mm
|
|
Max. Aperture
|
Panoramic: F1.0
Detail: F1.6–F3.6
|
|
Field of View
|
Panoramic:
H: 95°; V: 52.5° ; D: 116°
Detail:
H: 53.1°–3.4°; V: 30.4°–1.95°; D: 59.3°–3.9°
|
|
Optical Zoom
|
24×
|
|
Focus Control
|
Auto; Semi-Auto; Manual
|
|
Close Focus Distance
|
Panoramic: 0.2 m (0.66 ft)
Detail: 0.5 m–5 m (1.64 ft–16.4 ft)
|
|
Iris Control
|
Panoramic: Fixed
Detail: Auto; manual; fixed
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
Panorama:
102 m
(334.66 ft)
Detail:
1,928 m
(6325.46 ft)
|
Panorama:
40.8 m
(133.86 ft)
Detail:
771.2 m
(2530.18 ft)
|
Panorama:
20.4 m
(66.9 ft)
Detail:
385.6 m
(1265.09 ft)
|
Panorama:
10.2 m
(33.46 ft)
Detail:
192.8 m
(632.55 ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 360° endless
Tilt: –20° to +90°, auto flip 180°
|
|
Manual Control Speed
|
Pan: 0.1°–160°/s
Tilt: 0.1°–120°/s
|
|
Preset Speed
|
Pan: 240°/s; Tilt: 200°/s
|
|
Preset
|
300
|
|
Tour
|
8 (up to 32 presets per tour)
|
|
Pattern
|
5
|
|
Scan
|
5
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Preset, Tour, Scan, Track
|
|
PTZ Protocol
|
DH–SD
Pelco–P/D (auto recognition)
|
|
Intelligence
|
|
Face Detection
|
Yes
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking
|
|
Auto Tracking
|
Yes
|
|
Video
|
|
Video Compression
|
H.265, H.264B, H.264M, H.264H ,MJPEG, smart H.265, smart H.264
|
|
Streaming Capability
|
3 streams
|
|
Resolution
|
Panoramic:
4M (2560 X 1440) , 1080p (1920 × 1080) , 1.3M (1280 × 960) , 720p (1280 ×720) , D1 (704 × 576/704 × 480) , CIF (352 × 288/352 × 240)
Detail:
4M (2560 X 1440) , 1080p (1920×1080) , 1.3M (1280 × 960) , 720p (1280 ×720) , D1 (704 × 576/704 × 480) , CIF (352 × 288/352 × 240)
|
|
Default Bit Rate with Default Resolution
|
3072 Kbps (2560 × 1440, H.265)
|
|
Video Frame Rate
|
Panoramic:
Main stream: 4M/1080p/1.3M/720p (1–25/30 fps)
sub stream 1: D1/CIF (1–25/30 fps)
sub stream 2: 720p/CIF (1–25/30 fps)
Detail:
Main stream: 4M/1080p/1.3M/720p (1–25/30 fps)
sub stream 1: D1/CIF (1–25/30 fps)
sub stream 2: 720p/CIF (1–25/30 fps)
|
|
Bit Rate Control
|
Constant Bite Rate; Variable Bite Rate
|
|
Video Bit Rate
|
H. 265: 1024 Kbps–7936 Kbps
|
|
Day/Night
|
Panoramic: Color/B/W
Detail: Auto (ICR)/Color/B/W
|
|
BLC
|
Panoramic: Yes
Detail: Yes
|
|
WDR
|
Yes
|
|
HLC
|
Panoramic: Yes
Detail: Yes
|
|
White Balance
|
Panoramic: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Detail: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
|
|
Gain Control
|
Panoramic: Auto; manual
Detail: Auto; manual
|
|
Noise Reduction
|
Panoramic: 2D NR; 3D NR
Detail: 2D NR; 3D NR
|
|
Motion Detection
|
Yes
|
|
Region of Interest (RoI)
|
Yes
|
|
Defog
|
Panoramic: Electronic Defog
Detail: Electronic Defog
|
|
Flip
|
180°
|
|
S/N Ratio
|
≥ 55 dB
|
|
Certification
|
|
Certifications
|
CE: EN55032/EN55024/EN50130-4
FCC: 47 CFR FCC Part15, Subpart B,
Class A ANSI C63.4-2014
|
|
Audio
|
|
Audio Compression
|
G.711a; G.711Mu; G.726; MPEG2–Layer2; G722.1
|
|
Network
|
|
Network Port
|
RJ–45 (10/100 Base–T)
|
|
Network Protocol
|
HTTP, HTTPS, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, IPv6, 802.1x, Qos, FTP, UPnP, ICMP, SNMP, SNMPv, 1/v2c/v3 (MIB-2), IGMP, ARP, RTCP, RTP, PPPoE, TCP
|
|
Interoperability
|
ONVIF, CGI, Dahua SDK
|
|
Streaming Method
|
Unicast/Multicast
|
|
User/Host
|
20
|
|
Storage
|
FTP; Micro SD card (128 GB)
|
|
Browser
|
IE7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari
|
|
Management Software
|
Smart PSS, DSS, NVR
|
|
Mobile Client
|
IOS, Android, iPhone, iPad, Windows Phone
|
|
Port
|
|
Alarm I/O
|
2/1
|
|
Audio I/O
|
1/1
|
|
Two-way Audio
|
Yes
|
|
Alarm Linkage
|
Capture; preset; tour; pattern; recording; triggering on–off value output; audio; sending email
|
|
Alarm Event
|
Motion/tampering detection, audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; power exception detection
|
|
Power
|
|
Power Supply
|
36 VDC/2.23 A ± 25% (included)
|
|
Power Consumption
|
Basic: 20 W
Max. (illuminator + heater + PTZ working + sound and light alarm): 45 W
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +65 °C (–40 °F to +149 °F)
|
|
Operating Humidity
|
≤ 95%
|
|
Protection
|
IP66; TVS 6000 V lightning proof, surge protection and voltage transient protection
|
|
Structure
|
|
Casing
|
Plastic + aluminum alloy
|
|
Product Dimensions
|
358 mm × Φ202 mm (14.09" × 7.95")
|
|
Packaging Dimensions
|
510.0 mm × 312.0 mm × 312.0 mm (21.42" × 7.70" × 6.75") (L × W × H)
|
|
Net Weight
|
5.6 kg (12.35 lb)
|
|
Gross Weight
|
7.15 kg (15.77 lb)
|
