KTP05(S)

Technical Specification

Model

DHI-VTO3222E-P

System(VTO)

Main Processor

Embedded Processor

Operating System

Embedded Linux OS

Button Type

Mechanical

Interoperability

ONVIF

Network Protocol

SIP; P2P; IPv4; DNS; RTSP; RTP; TCP; UDP

Basic(VTO)

Camera

1/2.9" 2 MP CMOS

Field of View

H: 140°, V: 80°, D: 160°

WDR

120 dB

Noise Reduction

3D NR

Video Compression

H264, H265

Video Resolution

Main stream: 720p, WVGA, D1, CIF
Sub stream: 1080p, WVGA, D1, QVGA, CIF

Video Frame Rate

25 fps

Light Compensation

Auto white light

Day/Night

Color/B/W

Audio Compression

G.711a, G.711u, PCM

Audio Input

1

Audio Output

Built-in speaker

Audio Mode

Two-way audio

Audio Enhancement

Echo suppression, digital noise reduction

Audio Bit Rate

16 KHz, 16 bit

Function(VTO)

Communication Mode

2-wire

Unlock Mode

Card; password; remote unlock

Card Type

Mifare card

Auto Snapshot

Yes (SD card is inserted in the indoor monitor or door station)

Leave Videos

Yes (SD card is inserted in the indoor monitor or door station)

Storage

Supports Micro SD card (up to 256 GB)

Web Configuration

Yes

Performance(VTO)

Card Reading Distance

0 cm–3 cm (0"–1.18")

Casing Material

Aluminum alloy

Capacity(VTO)

Card Capacity

10000

Port(VTO)

RS-485

1

Wiegand

1

Alarm Input

1

Alarm Output

1

Power Output

1 (12 V, 600 mA)

Door Bell

1

Exit Button

1

Lock Control

1, normally closed by default

Network Port

1 × RJ-45, 10 Mbps/100 Mbps network port

Alarm(VTO)

Tamper Alarm

Yes

General(VTO)

Appearance Color

Silver

Power Supply

48 VDC, 0.4 A;
PoE (802.3af/at)

Power Adapter

Optional

Installation

Surface mount (The surface mount kit comes with the surface mount bracket)

Certifications

CE

Product Dimensions

200.0 mm × 98.0 mm × 35.4 mm (7.87" × 3.86" × 1.39")

Protection

IK08, IP65 (Silicone sealant is needed, see the quick start guide)

Operating Temperature

–40 °C to +60 °C (–40 °F to +140°F)

Operating Humidity

10%–95% (RH), non-condensing

Operating Altitude

Beneath 3000 m (9842.52 ft)

Operating Environment

Outdoor

Power Consumption

≤5 W (standby), ≤7 W (working)

Gross Weight

692 g (1.53 lb)

Storage Humidity

30%–75% (RH)

Storage Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Model

DHI-VTH2621GW-WP

System (VTH)

Main Processor

Embedded Processor

Operating System

Embedded Linux OS

Network Protocol

RTSP; DNS; RTP; SIP; SSH

Basic (VTH)

Screen Type

Capacitive Touchscreen

Display Screen

7" TFT

Screen Resolution

1024 (H) × 600 (V)

Audio Compression

G.711a; G.711u; PCM

Audio Input

1

Audio Output

Built-in speaker

Audio Mode

Two-way audio

Audio Enhancement

Echo suppression

Audio Bit Rate

16 KHz; 16 bit

Function (VTH)

Communication Mode

Full digital

Information Release

Receive and view text information released by the management center

Leave Videos

Yes (SD card inserted in VTH is needed)

DND Mode

Do not disturb period can be set

Number of Extensions

Villa: 9 extensions;
Apartment: 4 extensions

Port (VTH)

Alarm Input

6

Alarm Output

1

Door Bell

Yes (reuse the alarm input port)

Network Port

1 × RJ-45 10/100 Mbps Ethernet port

Performance (VTH)

Casing Material

PC + ABS

General (VTH)

Appearance Color

White

Power Supply

12 VDC, 1 A;
Standard PoE

Power Adapter

Optional

Installation

Surface Mount

Certifications

CE

Accessory

Bracket and alarm ribbon cable (included)

Product Dimensions

189.6 mm × 134.6 mm × 26.0 mm (7.50" × 5.30" × 1.00")

Operating Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

10%–95% (RH), non-condensing

Operating Altitude

Beneath 3000 m (9842.52 ft)

Operating Environment

Indoor

Power Consumption

≤2 W (standby), ≤6 W (working)

Gross Weight

575 g (1.27 lb)

Storage Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Storage Humidity

30%–75% (RH)

Model

DH-PFS3006-4ET-36

System (Networking Device)

Main Processor

Embedded Processor

Port (Networking Device)

Network Port

4 × PoE ports with 10/100 Mbps Base-TX 2 uplink ports with 10/100 Mbps Base-TX

General (Networking Device)

Power Supply

Built-in power supply: 100–240 VAC

Certifications

CE; FCC

Product Dimensions

194.0 mm × 108.1 mm × 35.0 mm (7.64" × 4.26" × 1.38") (L × W × H)

Operating Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

10%–90% (RH), non-condensing

Power Consumption

Idling: 0.5 W;
Full load: 36 W

Gross Weight

1.11 kg (2.15 lb)
