Camera
|
|
Image Sensor
|
1/2.8" CMOS
|
|
Pixel
|
4 MP
|
|
Max. Resolution
|
2560 (H) × 1440 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
512 MB
|
|
Electronic Shutter Speed
|
1/1 s–1/30,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux (IR light on)
|
|
Illumination Distance
|
50 m (164.04 ft) (IR)
30 m (98.43 ft) (Warm light)
|
|
Illuminator On/Off Control
|
Zoom Prio; Manual; Auto; Off
|
|
Illuminator Number
|
2 (IR)
2 (Warm light)
1 (Red light)
1 (Blue light)
|
|
Lens
|
|
Focal Length
|
2.7 mm–13.5 mm
|
|
Max. Aperture
|
F1.6–F3.0
|
|
Field of View
|
H: 94.9°–30.1°;
V: 51°–17.1°;
D: 112.3°–34.6°
|
|
Optical Zoom
|
5×
|
|
Focus Control
|
Auto; semi-auto; manual
|
|
Close Focus Distance
|
1.5 m (4.92 ft)
|
|
Iris Control
|
Fixed
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
270 m
(885.83 ft)
|
106.6 m
(349.74 ft)
|
54 m
(177.17 ft)
|
27 m
(88.58 ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 355°
Tilt: –15° to +90°
|
|
Manual Control Speed
|
Pan: 0.1°/s–36°/s
Tilt: 0.1°/s–25.8°/s
|
|
Preset Speed
|
Pan: 35.7°/s; Tilt: 27.1°/s
|
|
Preset
|
300
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Preset
|
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking
|
|
Face Detection
|
Supports face detection, snapshot, and face enhancement;
Supports face cutout: Face, one-inch photo;
Capturing strategies include real-time capturing and quality first
|
|
Auto Tracking Lite
|
Yes
|
|
SMD
|
Yes
|
|
Active Deterrence
|
|
Light Warning
|
Red and blue light warning
Flash duration: 5 s–30 s
Flash frequency: high, medium, low
|
|
Sound Warning
|
Offers 11 types of sound alarms, and supports importing up to 10 custom sound alarms. The sound alarm can be set to play 1 to 10 times
|
|
Video
|
|
Video Compression
|
H.264H;H.264B;Smart H.265+; H.264;H.265;MJPEG(Sub Stream);Smart H.264+
|
|
Streaming Capability
|
3 streams
|
|
Resolution
|
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p(1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288)
|
|
Video Frame Rate
|
Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps)
Sub stream 1: D1/CIF/VGA@ (1–25/30 fps)
Sub stream 2: 720p @(1–25/30 fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 96 kbps–14848 kbps
H.265: 38 kbps–8960 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
WDR
|
120 dB
|
|
HLC
|
Yes
|
|
White Balance
|
Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
2D NR; 3D NR
|
|
Motion Detection
|
Yes
|
|
Region of Interest (RoI)
|
Yes
|
|
Image Stabilization
|
Electronic (EIS)
|
|
Defog
|
Electronic
|
|
Digital Zoom
|
16×
|
|
Image Rotation
|
180°
|
|
S/N Ratio
|
≥55 dB
|
|
Audio
|
|
Audio Compression
|
G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; PCM
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Network Protocol
|
FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RTP;802.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;UDP;IGMP;SMB;HTTP;SSL;DHCP;SMTP;Qos;RTSP;ARP
|
|
Interoperability
|
CGI;SDK;ONVIF (Profile S&G&T);P2P
|
|
Streaming Method
|
Unicast/Multicast
|
|
User/Host
|
20 (total bandwidth: 64 M)
|
|
Storage
|
FTP/SFTP; Micro SD card (512 GB); NAS
|
|
Browser
|
IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions
|
|
Management Software
|
DMSS;DSS Pro
|
|
Mobile Client
|
iOS;Android
|
|
Certification
|
|
Certifications
|
CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
|
|
Port
|
|
Audio Input
|
1 channel (LINE IN, bare wire,built-in mic (mutually exclusive))
|
|
Audio Output
|
1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive))
|
|
Alarm Linkage
|
Capture; recording; send email; preset; alarm digital input; audio; warning light
|
|
Alarm Event
|
Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
|
|
Alarm I/O
|
1/1
|
|
Audio I/O
|
1/1
|
|
Power
|
|
Power Supply
|
12 VDC, 2 A ± 10%
PoE+ (802.3at)
|
|
Power Consumption
|
Basic: 4.5 W
Max.: 15 W (illuminator + PTZ + speaker + heating glass)
|
|
Environment
|
|
Operating Temperature
|
–30 °C to +60 °C (–22 °F to +140 °F)
|
|
Operating Humidity
|
≤95%
|
|
Protection
|
IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection
|
|
Structure
|
|
Product Dimensions
|
142.6 mm × 140 mm × 236.1 mm (5.61" × 5.51" ×
9.29")
|
|
Net Weight
|
1.5 kg (3.31 lb)
|
|
Gross Weight
|
2.1 kg (4.63 lb)
|
| The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model. |
