Camera
|
|
Image Sensor
|
1/1.8" CMOS
|
|
Pixel
|
4K
|
|
Max. Resolution
|
3840(H) x 2160(V)
|
|
ROM
|
4 GB
|
|
RAM
|
1 GB
|
|
Electronic Shutter Speed
|
1 s–1/30,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux@F1.6 (IR light on)
|
|
Illumination Distance
|
150 m (492.13 ft) (IR)
|
|
Illuminator On/Off Control
|
Zoom Prio; Manual; Auto; Off
|
|
Illuminator Number
|
4 (IR)
|
|
Lens
|
|
Focal Length
|
5.4 mm–135 mm
|
|
Max. Aperture
|
F1.6–F4.0
|
|
Field of View
|
H: 61.6°–3.6°; V: 35.7°–2°; D: 66.6°–4°
|
|
Optical Zoom
|
25×
|
|
Focus Control
|
Auto; semi-auto; manual
|
|
Close Focus Distance
|
0.1 m–2 m
|
|
Iris Control
|
Auto; manual; fixed
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2700 m (8858.27 ft)
|
1066 m (3497.38 ft)
|
540 m (1771.65 ft)
|
270 m (885.83 ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 360° endless
Tilt: –15° to +90°, auto flip 180°
|
|
Manual Control Speed
|
Pan: 0.1°/s–300°/s
Tilt: 0.1°/s–140°/s
|
|
Preset Speed
|
Pan: 400°/s; Tilt: 300°/s
|
|
Preset
|
300
|
|
Tour
|
8 (up to 32 presets per tour)
|
|
Pattern
|
5
|
|
Scan
|
5
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Pattern; Preset; Scan; Tour
|
|
PTZ Protocol
|
DH-SD Pelco-P/D (Auto recognition)
|
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking
|
|
Face Detection
|
Supports face detection,face bounding box, capturing snapshots, uploading face snapshots, enhancing face images, and selecting a preferred image among a group of snapshots. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. The attributes are gender, age, glasses, mask, mustache and expressions. The expressions are angry, sad, hate, scared, surprised, calm, happy and confused. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots.
|
|
Video Metadata
|
Detects motor and non-motor vehicles, faces and human bodies. It also performs tracking, takes snapshots, uploads high-quality face images and optimizes images. It extracts attributes from motor vehicles, detecting up to 10 attributes for them.
|
|
People Counting
|
Uses advanced image processing technology to extract depth information from images. The extracted information is then processed by advanced, deep learning algorithms to analyze and detect human bodies, and track targets in real time. The camera provides statistics for separate individuals' entrance and exit with up to 95% counting accuracy.
|
|
Auto Tracking
|
Yes
|
|
SMD
|
SMD 4.0
|
|
Auto Patrol
|
It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets.
|
|
Video
|
|
Video Compression
|
H.265; H.264B; H.264; H.264H; MJPEG(Sub Stream 1); smart H.265+; smart H.264+
|
|
Streaming Capability
|
3 streams
|
|
Resolution
|
4K (3840 × 2160); 4M (2560 × 1440); 3M (2048 × 1536); 1080p (1920 × 1080); 960p (1920 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); VGA (640 × 480)
|
|
Video Frame Rate
|
Main stream: 8M/4M/3M/1080p/1.3M/720p (1–25/30 fps)
Sub stream 1: D1/CIF/VGA (1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p (1–25/30 fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 128 kbps–16,384 kbps
H.265: 51 kbps–12,288 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
WDR
|
120 dB
|
|
HLC
|
Yes
|
|
White Balance
|
Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
2D NR; 3D NR
|
|
Motion Detection
|
Yes
|
|
Region of Interest (RoI)
|
Yes
|
|
Image Stabilization
|
Electronic(EIS)
|
|
Defog
|
Electronic
|
|
Digital Zoom
|
16×
|
|
Image Rotation
|
180°
|
|
Privacy Masking
|
Up to 24 areas can be set, with up to 8 areas in the same view;
multiple colors available
|
|
S/N Ratio
|
≥ 55 dB
|
|
Audio
|
|
Audio Compression
|
PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Network Protocol
|
FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP
|
|
Interoperability
|
ONVIF(Profile S&G&T);CGI;SDK
|
|
Streaming Method
|
Unicast/Multicast
|
|
User/Host
|
20 (total bandwidth: 64 M)
|
|
Storage
|
Micro SD card (512 GB); FTP/SFTP; NAS
|
|
Browser
|
IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions
|
|
Management Software
|
DMSS; DSS Pro
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
Certifications
|
CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
UL: UL60950-1+CAN/CSA C22.2,No.60950-1
|
|
Port
|
|
Audio Input
|
1 channel (LINE IN, bare wire)
|
|
Audio Output
|
1 channel (LINE OUT, bare wire)
|
|
Alarm Linkage
|
Capture; recordings; send email; preset; tour; pattern; alarm digital input
|
|
Alarm Event
|
Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card status detection; memory space detection
|
|
Alarm I/O
|
2/1
|
|
Audio I/O
|
1/1
|
|
Power
|
|
Power Supply
|
24 VDC/2.5 A ± 25%
PoE+ (802.3at)
|
|
Power Consumption
|
Basic: 12W
Max: 21W(IR light+PTZ+Heater+Fan)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +70 °C (–40 °F to +158 °F)
|
|
Operating Humidity
|
≤ 95%
|
|
Storage Temperature
|
–40 °C to +70 °C (–40 °F to +158 °F)
|
|
Storage Humidity
|
≤ 95%
|
|
Protection
|
IP67, IK10, TVS 6000 V lightning proof; surge protection; voltage transient protection
|
|
Structure
|
|
Product Dimensions
|
Φ190 mm × 332 mm (Φ7.48" × 13.07")
|
|
Net Weight
|
4.7 kg (10.36 lb)
|
|
Gross Weight
|
8.0 kg (17.64 lb)
|
