Camera
|
|
Image Sensor
|
1/2.8"CMOS
|
|
Pixel
|
2 MP
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
512 MB
|
|
Electronic Shutter Speed
|
1/1 s–1/30,000 s
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux (IR light)
|
|
Illumination Distance
|
250 m (656.17 ft) (IR)
|
|
Illuminator Number
|
6 (IR)
|
|
Lens
|
|
Focal Length
|
4.8 mm–120 mm
|
|
Max. Aperture
|
F1.6–F3.5
|
|
Field of View
|
H: 58.5°–2.8°; V: 33.2°–1.5°; D: 67.5°–3.2°
|
|
Optical Zoom
|
25×
|
|
Focus Control
|
Auto; semi-auto; manual
|
|
Close Focus Distance
|
0.1 m–1.0 m (0.34 ft–3.28 ft)
|
|
Iris Control
|
Auto; manual
|
|
DORI Distance
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
1655.2 m (5430.36 ft)
|
653.8 m (2145.00 ft)
|
331.0 m
(1,086.07 ft)
|
165.5m (543.04 ft)
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 360° endless
Tilt: –20° to +90°, auto flip 180°
|
|
Manual Control Speed
|
Pan: 0.1°/s–200°/s
Tilt: 0.1°/s–120°/s
|
|
Preset Speed
|
Pan: 300°/s; Tilt: 200°/s
|
|
Preset
|
300
|
|
Tour
|
8 (up to 32 presets per tour)
|
|
Pattern
|
5
|
|
Scan
|
5
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Pattern; Preset; Scan; Tour
|
|
PTZ Protocol
|
DH-SD
Pelco-P/D (Auto recognition)
|
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification
|
|
Face Detection
|
Supports face detection,face bounding box, capturing snapshots, and enhancing face images. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, and quality first
|
|
SMD
|
SMD 3.0
|
|
Auto Patrol
|
It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets
|
|
Video
|
|
Video Compression
|
H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG(Sub Stream); Smart H.264+
|
|
Streaming Capability
|
3 streams
|
|
Resolution
|
1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576); CIF (352 × 288); VGA (640 × 480)
|
|
Video Frame Rate
|
Main stream: 1080p/1.3M/720p@(1–25/30 fps)
Sub stream 1: D1/VGA/CIF@(1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p@(1–25/30 fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 2048 Kbps–8192 Kbps
H.265: 768 Kbps–6400 Kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
WDR
|
120dB
|
|
HLC
|
Yes
|
|
White Balance
|
Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
2D NR; 3D NR
|
|
Motion Detection
|
Yes
|
|
Region of Interest (RoI)
|
Yes
|
|
Image Stabilization
|
Electronic (EIS)
|
|
Defog
|
Electronic
|
|
Digital Zoom
|
16×
|
|
Image Rotation
|
180°
|
|
Privacy Masking
|
Up to 24 areas can be set, with up to 8 areas in the same view;multiple colors available
|
|
S/N Ratio
|
≥ 55 dB
|
|
Audio
|
|
Audio Compression
|
G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G723; PCM
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
Network Protocol
|
TCP; FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; IP Filter; SMB; HTTP; SSL; DHCP; SMTP; SNMPv1/v2c/v3(MIB-2); Qos; RTSP; ARP
|
|
Interoperability
|
CGI; Dahua SDK; API; SDK; ONVIF(Profile S&G&T)
|
|
Streaming Method
|
Unicast/Multicast
|
|
User/Host
|
20 (total bandwidth: 64 M)
|
|
Storage
|
DMSS; FTP; Micro SD card (512 GB); NAS
|
|
Browser
|
IE 7 and later versions
Chrome 45 and later versions
Firefox 52 ESR and earlier versions
Safari
|
|
Management Software
|
DMSS; DSS Pro
|
|
Mobile Client
|
iPhone; iPad; iOS; Android
|
|
Certification
|
CE-EMC: EN 55032; EN 61000-3-3;
EN 61000-3-2; EN 50130-4; EN 55035
CE-LVD: EN 62368-1
FCC: 47 CFR FCC Part15, Subpart B, NSI C63.4
|
|
Port
|
|
Analog Output
|
1 channel (CVBS output, BNC)
|
|
RS-485
|
1 (baud rate: 1200 bps–9600 bps)
|
|
Audio Input
|
1 channel
|
|
Audio Output
|
1 channel
|
|
Alarm Linkage
|
Capture; preset; tour; pattern; recording; alarm digital input; send email
|
|
Alarm Event
|
Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card status detection; memory space detection
|
|
Alarm I/O
|
7/2
|
|
Audio I/O
|
1/1
|
|
Power
|
|
Power Supply
|
24 VDC/2.5 A ± 25%
PoE+ (802.3at)
|
|
Power Consumption
|
Basic: 14.0W
Max.: 25.2 W (illuminator + AI functions)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
≤ 95%
|
|
Protection
|
IP67, IK10, TVS 8000 V lightning proof; surge protection; voltage transient protection
|
|
Structure
|
|
Product Dimensions
|
337.4 mm × Φ209.1 mm (13.28" × Φ8.23")
|
|
Net Weight
|
5.8 kg (12.79 lb)
|
|
Gross Weight
|
9.4 kg (20.72 lb)
|
