Camera
|
|
Image Sensor
|
1/2.7" CMOS
|
|
Max. Resolution
|
3840 (H) × 2160 (V)
|
|
Pixel
|
4K
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s
|
|
Min. Illumination
|
0.02 Lux/F2.0, 30 IRE, 0 Lux IR on
|
|
S/N Ratio
|
＞65 dB
|
|
Illumination Distance
|
20 m (65.6 ft)
|
|
Illumination Type
|
IR
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
1 (IR light)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Mount Type
|
M12
|
|
Focal Length
|
2.8 mm
|
|
Max. Aperture
|
2.8 mm: F2.0
|
|
Field of View
|
2.8 mm: D: 125°; H: 105°; V: 56°
|
|
Iris Type
|
Fixed iris
|
|
Close Focus Distance
|
2.8 mm: 1.0 m (3.3 ft)
|
|
DORI Distance
|
2.8 mm: D: 74.7 m (245.1 ft); O: 29.9 m (98.1 ft); R: 14.9 m (48.9 ft); I: 7.5 m (24.6 ft)
|
|
Video
|
|
Frame Rate
|
CVI: 4K@25/30 fps; 4K@15 fps; 5M@20 fps;
4M@25 fps/30 fps;
AHD: 4K@15 fps;
TVI: 4K@15 fps;
CVBS: 960H
|
|
Resolution
|
4K (3840 × 2160); 5M (2592 × 1944); 4M (2560 × 1440); 960H (960 × 576/960 × 480)
|
|
Day/Night
|
ICR auto switch
|
|
BLC Mode
|
BLC/HLC/DWDR
|
|
WDR
|
DWDR
|
|
White Balance
|
Auto/Manual
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
2D
|
|
Smart IR
|
Yes
|
|
Mirror
|
Off/On
|
|
Privacy Masking
|
Off/On (8 Area, Rectangle)
|
|
Certifications
|
|
Certifications
|
CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
IEC 62368-1:2014 (Second Edition)
|
|
Port
|
|
Video Output
|
1 BNC output
Support CVI/TVI/AHD/CVBS
|
|
Power
|
|
Power Supply
|
12V ±30% DC
|
|
Power Consumption
|
Max 8.5W (12V DC, IR on)
|
|
PIR Parameters
|
|
Detection Component
|
Pyroelectric infrared sensor
|
|
Detection Range
|
10 m(32.8 ft), 110°
|
|
Recommended Installation Height
|
2.2 m–3 m (7.2 ft-9.8 ft)
|
|
Recommended Environment Temperature for PIR
|
–10°C to 50°C (14°F to 122°F)
|
|
Active Deterrence Parameters
|
|
White Light Warning
|
Solid: 5 s–30 s; flash: 5 s–30 s; frequency: high/medium/low
|
|
Sound Warning
|
Audio 1/2/3; Volume: high/medium/low; duration: 5 s–30 s; 110 dB
|
|
Environment
|
|
Operating Temperature
|
–40°C to +60°C (–40°F to 140°F);<95% (non-condensation)
|
|
Storage Temperature
|
–40°C to +60°C (–40°F to 140°F);<95% (non-condensation)
|
|
Ingress Protection
|
IP67
|
|
Structure
|
|
Casing
|
Inner core: Metal + plastic
Cover: Plastic
|
|
Camera Dimensions
|
Φ109.9 mm × 100.9 mm (Φ4.33" × 3.97")
|
|
Net Weight
|
0.30 kg (0.66 lb)
|
|
Gross Weight
|
0.39 kg (1.08 lb)
|
