System
|
|
Main Processor
|
Embedded processor
|
|
Operating System
|
Embedded Linux
|
|
Operating Interface
|
Web; Local GUI
|
|
Perimeter Protection
|
|
Perimeter Performance AI by Recorder (Number of Channels)
|
Advanced Model: 2 channel, 10 IVS for each channel
General Model: 4 channels, 10 IVS for each channel
|
|
Face Detection
|
|
Face Attributes
|
Gender; age group; glasses; expressions; face mask; beard
|
|
Face Detection Performance of AI by Recorder (Number of Channels)
|
2 channels (up to 12 face images/s)
|
|
Face Recognition
|
|
Face Database Capacity
|
Up to 10 face databases with 10000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture
|
|
Face Recognition Performance of AI by Recorder (Number of Channels)
|
2 channels
|
|
SMD Plus
|
|
SMD Plus by Recorder
|
16 channels: Secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change
|
|
Audio and Video
|
|
Analog Camera Input
|
16 BNC ports, CVI access by default, supports HDCVI/AHD/TVI/CVBS auto-detect
|
|
Camera Input
|
1. CVI: 5MP@20fps, 5MP@25fps, 5MP@10/12.5fps, 4MP@25/30fps, 1080p@25/30fps, 720p@50/60fps, 720p@25/30fps.
2. TVI: 5MP@20fps, 4MP@25/30fps, 1080p@25/30fps, 720p@25/30fps.
3. AHD: 5MP@20fps, 4MP@25/30fps, 1080p@25/30fps, 720p@25/30fps.
|
|
IP Camera Input
|
Up to 24 channels of IPC access
8 IP channels by default + 16 channels (analog channels are converted to IP channels)
incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps
*After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled.
|
|
Encoding Capacity
|
Main stream:
5MP Mode: 4-ch 5MP@(1-6fps); other channels 5M-N@(1-12fps)
5M-N Mode:
All channel 5M-N@(1–12fps);4M-N,1080p@(1–15fps); 1080N, 720p, 960H, D1,CIF@(1–25/30fps)
Sub stream: D1, CIF@(1–15fps)
|
|
Dual-stream
|
Yes
|
|
Video Frame Rate
|
PAL: 1 fps–25 fps.
NTSC: 1 fps–30 fps.
|
|
Video Bit Rate
|
32 Kbps–6144 Kbps Per Channel
|
|
Audio Sampling
|
8 KHz, 16 bit
|
|
Audio Bit Rate
|
64 Kbps
|
|
Video Output
|
1 HDMI ,1 VGA
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
It changes to 1920 × 1080, 1280 × 1024, 1280 × 720 when Face or IVS&SMD is selected in AI Mode.
|
|
Multi-screen Display
|
When IP extension mode not enabled: 1/4/8/9/16
When IP extension mode enabled: 1/4/8/9/16/25
|
|
Third-party Camera Access
|
Onvif, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Samsung
|
|
Compression Standard
|
|
Video Compression
|
AI Coding/H.265+/H.265/H.264+/H.264
|
|
Audio Compression
|
G.711A/G.711u/PCM
|
|
Network
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)
|
|
Mobile Phone Access
|
iPhone, iPad, Android
|
|
Interoperability
|
ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK
|
|
Browser
|
Chrome, IE9 or above, Firefox
|
|
Network Mode
|
Single-address mode
|
|
Recording Playback
|
|
Record Mode
|
General, motion detection; intelligent; alarm; POS
|
|
Recording Playback
|
1/4/9/16
It changes to 1/4/9 split when Face or IVS&SMD is selected in AI Mode.
|
|
Backup Method
|
USB Device/Network
|
|
Playback Mode
|
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
|
|
Alarm
|
|
General Alarm
|
Motion detection, Video Loss, tampering
|
|
Anomaly Alarm
|
No disk, disk error, low space, offline, ip conflict, MAC conflict
|
|
Intelligent Alarm
|
Face detection, face recognition, perimeter protection
|
|
Alarm Linkage
|
Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email
|
|
Ports
|
|
Audio Input
|
1-channel RCA (external)
16-channel BNC (coaxial audio)
|
|
Audio Output
|
1-channel RCA
|
|
Two-way Talk
|
Yes (share the same audio input with the first channel)
|
|
HDD Interface
|
1 SATA Port, up to 16TB, the maximum HDD capacity varies with environment temperature
|
|
RS-485
|
1 Port, for PTZ Control
|
|
USB
|
2 (1 front USB 2.0 port, 1 rear USB 3.0 port)
|
|
HDMI
|
1
|
|
VGA
|
1
|
|
Network Port
|
1 (10/100/1000 Mbps Ethernet port, RJ-45)
|
|
General
|
|
Power Supply
|
DC12V, 2A
|
|
Power Consumption
|
Lower than 12 W
|
|
Net Weight
|
1.17 kg (2.58 lb)
|
|
Gross Weight
|
1.57 kg (3.46 lb)
|
|
Product Dimensions
|
Compact 1U, 260.0 mm × 237.9 mm × 47.6 mm
10.24" × 9.37" × 1.87" (W × D × H)
|
|
Packaging Dimensions
|
333.0 mm × 89.0 mm × 315.0 mm
13.11" × 3.50" × 12.40" (W × D × H)
|
|
Operating Temperature
|
–10 °C to +55 °C (+14 °F to +131 °F)
|
|
Operating Humidity
|
10%–90%
|
|
Installation
|
Desktop
|
|
Certifications
|
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
FCC: Part 15 Subpart B
|
