System
|
|
Main Processor
|
Industrial-grade processor
|
|
Operating System
|
Embedded Linux
|
|
Operating Interface
|
Web; Local GUI
|
|
Perimeter Protection
|
|
Perimeter Performance AI by Recorder (Number of Channels)
|
Advanced Model: 6 channels, 10 IVS for each channel
General Model: 12 channels, 10 IVS for each channel
|
|
Face Detection
|
|
Face Attributes
|
Gender; age group; glasses; expressions; face mask; beard
|
|
Face Detection Performance of AI by Recorder (Number of Channels)
|
6 channels (up to 12 face images/s each channel)
|
|
Face Recognition
|
|
Face Database Capacity
|
Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries & regions and state can be added to each face image
|
|
Face Recognition Performance of AI by Recorder (Number of Channels)
|
6 channels
|
|
SMD Plus
|
|
SMD Plus by Recorder
|
32 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
|
|
Audio and Video
|
|
Analog Camera Input
|
32 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
|
|
Camera Input
|
1. CVI: 4K@25/30 fps; 6 MP@20 fps; 5 MP@20 fps; 5 MP@25 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps.2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps
|
|
IP Camera Input
|
Up to 32 channels of IPC access
32 channels (analog channels are converted to IP channels)
incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps
|
|
Encoding Capacity
|
Main stream:
4K@(1fps-7fps); 6 MP@(1fps-10fps); 5 MP@(1fps-12fps); 4K-N, 4 MP, 3 MP@(1fps-15fps); 4M-N, 1080p, 720p, 960H, D1,CIF@(1fps–25/30fps);
Sub stream: 960H@(1fps–15fps); D1/CIF@(1 fps–25/30fps)
|
|
Dual-stream
|
Yes
|
|
Video Bit Rate
|
32 kbps–6144 kbps
|
|
Audio Sampling
|
8 kHz, 16 bit
|
|
Audio Bit Rate
|
64 kbps
|
|
Video Output
|
2 HDMI, 1 VGA, 1 TV
VGA/HDMI2: 1920 × 1080, 1280 × 1024, 1280 × 720
HDMI1: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
*Heterogeneous video sources output for HDMI2 is configurable.
|
|
Multi-screen Display
|
1/4/8/9/16/25/36
|
|
Third-party Camera Access
|
ONVIF; Panasonic; Sony; Axis; Arecont; Samsung
|
|
Compression Standard
|
|
Video Compression
|
AI Coding; Smart H.265+; H.265; Smart H.264+; H.264
|
|
Audio Compression
|
G.711a; G.711u; PCM
|
|
Network
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P
|
|
Mobile Phone Access
|
IOS; Android
|
|
Interoperability
|
ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK
|
|
Browser
|
Chrome, IE9 or later, Firefox
|
|
Network Mode
|
Single-address mode
|
|
Recording Playback
|
|
Record Mode
|
General, motion detection; intelligent; alarm; POS
|
|
Recording Playback
|
1/4/9/16
|
|
Backup Method
|
USB device and network
|
|
Playback Mode
|
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
|
|
Storage
|
|
Disk Group
|
Yes
|
|
Alarm
|
|
General Alarm
|
Motion detection; video loss; tampering; local alarm
|
|
Anomaly Alarm
|
No disk; storage error; disk full; camera offline; IP conflict; MAC conflict
|
|
Intelligent Alarm
|
Face detection; face recognition; perimeter protection
|
|
Alarm Linkage
|
Record; snapshot (panoramic); IPC external alarm output; access controller; voice prompt; buzzer; log; preset; email
|
|
Ports
|
|
TV Output
|
1 channel
|
|
Audio Input
|
4-channel BNC
32-channel BNC (Coaxial Audio)
|
|
Audio Output
|
1-channel BNC
|
|
Two-way Talk
|
1-channel BNC
|
|
Alarm Input
|
16 channels
|
|
Alarm Output
|
6 channels (5-channel relay output, 1-channel 12 V 1 A output)
|
|
HDD Interface
|
4 SATA ports, up to 16TB capacity for each disk. The maximum HDD capacity varies with environment temperature
|
|
eSATA
|
1
|
|
RS-232
|
1 port, for PC Communication & Keyboard
|
|
RS-485
|
1 port, for PTZ control
|
|
USB
|
3 (1 front USB 2.0 port, 2 rear USB 3.0 ports)
|
|
HDMI
|
2
|
|
VGA
|
1
|
|
Network Port
|
1 (10/100/1000 Mbps Ethernet port, RJ-45)
|
|
General
|
|
Power Supply
|
100-240 VAC, 50/60 Hz
|
|
Power Consumption
|
<30 W (without HDD)
|
|
Net Weight
|
4.90 kg (10.81 lb)
|
|
Gross Weight
|
7.20 kg (15.88 lb)
|
|
Product Dimensions
|
440.0 mm × 420.2 mm × 76.0 mm (17.32'' × 16.54'' × 2.99'') (W × D × H)
|
|
Packaging Dimensions
|
529.0 mm × 499.0 mm × 211.0 mm (20.83" × 19.65" × 8.31") (W × D × H)
|
|
Operating Temperature
|
–10 °C to +55 °C (14 °F to +131 °F)
|
|
Operating Humidity
|
10%–90% (RH)
|
|
Installation
|
Rack or desktop
|
|
Certifications
|
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
FCC: Part 15 Subpart B
|
