Camera
|
|
Image Sensor
|
1/2.7” 8Megapixel progressive CMOS
|
|
Max. Resolution
|
3840 (H) × 2160 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
256 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.008 Lux@F1.5
|
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
40 m (131.2 ft)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
2 (IR LED)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–355°
Tilt: 0°–67°
Rotation: 0°–355°
|
|
Lens
|
|
Lens Type
|
Motorized vari-focal
|
|
Mount Type
|
φ14
|
|
Focal Length
|
2.7 mm–13.5 mm
|
|
Max. Aperture
|
F1.5
|
|
Field of View
|
Pan: 113°–31°
Tilt: 58°–17°
Diagonal: 138°–36°
|
|
Iris Type
|
Fixed
|
|
Close Focus Distance
|
0.8m–0.8m (2.62 ft–2.62 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
W
|
85.3 m
(279.9 ft)
|
34.1 m
(111.9 ft)
|
17 m
(55.8 ft)
|
8.5 m
(27.9 ft)
|
|
T
|
280 m
(918.6 ft)
|
112 m
(367.5 ft)
|
56 m
(183.7 ft)
|
28 m
(91.9 ft)
|
|
Smart Event
|
|
IVS
|
Tripwire; intrusion
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+/ Smart H.264+
|
|
Video Frame Rate
|
Main stream:
3840 × 2160 (1 fps–15 fps)
2688 × 1520 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
|
|
Stream Capability
|
2 streams
|
|
Resolution
|
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2592 × 1944 (2592 × 1944); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
White Balance
|
Auto/natural/street lamp/outdoor/manual/regional custom
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest(RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Supports 90°/270° with 3840 × 2160 resolution and lower.)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Audio
|
|
Audio Compression
|
G.711a; G.711Mu; G.726
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; motion detection; video tampering; tripwire; intrusion; illegal access; voltage detection; audio detection; safety exception; local alarm
|
|
Network
|
|
Network
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
|
|
Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
|
|
Interoperability
|
ONVIF(Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
|
|
User/Host
|
20
|
|
Storage
|
FTP; SFTP; Micro SD Card (support max. 256 GB); NAS
|
|
Browser
|
IE
Chrome
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Phone
|
IOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
|
|
Port
|
|
Audio Input
|
1 channel (RCA port)
|
|
Audio Output
|
1 channel (RCA port)
|
|
Alarm Input
|
1 channel In: 5mA 5V DC
|
|
Alarm Output
|
1 channel Out: 300mA 12V DC
|
|
Power
|
|
Power Supply
|
12V DC/PoE (802.3af)
|
|
Power Consumption
|
< 7.4W
|
|
Environment
|
|
Operating Conditions
|
–30°C to +60°C (–22°F to +140°F)/less than ≤ 95% RH
|
|
Storage Temperature
|
–40°C to +60°C (–40°F to +140°F)
|
|
Protection
|
IP67; IK10
|
|
Structure
|
|
Casing
|
Metal
|
|
Dimensions
|
Φ122 mm × 88.9 mm (Φ4.80" × 3.50")
|
|
Net Weight
|
0.47 kg (1.1 lb)
|
|
Gross Weight
|
0.63 kg (1.4 lb)
|
