Camera
|
|
Image Sensor
|
1/2.7" CMOS
|
|
Max. Resolution
|
2688 (H) × 1520 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
512 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.003 lux@F1.0 (Color, 30 IRE)
0.0003 lux@F1.0 (B/W, 30 IRE)
0 lux (illuminator on)
|
|
S/N Ratio
|
﹥56 dB
|
|
Illumination Distance
|
Up to 50 m (164.04 ft) (IR)
Up to 40 m (131.23 ft) (warm light)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
2 (IR LED)
2 (warm light)
|
|
Angle Adjustment
|
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Motorized vari-focal
|
|
Mount Type
|
φ16
|
|
Focal Length
|
2.7 mm–13.5 mm
|
|
Max. Aperture
|
F1.0
|
|
Field of View
|
Horizontal: 103°–33°
Vertical: 54°–18°
Diagonal: 124°–38°
|
|
Iris Type
|
Fixed
|
|
Close Focus Distance
|
1.5 m (4.92 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
W
|
65.2 m (213.91 ft)
|
26.1 m
(85.63 ft)
|
13.0 m
(42.65 ft)
|
6.5 m
(21.33 ft)
|
|
T
|
186.6 m (612.20 ft)
|
74.6 m
(244.75 ft)
|
37.3 m
(122.38 ft）
|
18.7 m
(61.35 ft)
|
|
Professional, intelligent
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
|
|
SMD 4.0
|
Less false alarm, longer detection distance
|
|
Quick Pick
|
With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events
|
|
Smart Search
|
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
|
|
AI SSA
|
Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions.
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
AI Coding
|
AI H.265; AI H.264
|
|
Video Frame Rate
|
Main stream: 2688 × 1520@(1 fps–30 fps)
Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps)
Third stream:1920 × 1080@(1 fps–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
|
|
Stream Capability
|
3 streams
|
|
Resolution
|
4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
Scene Self-adaptation
|
Yes
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Image Stabilization
|
Electronic Image Stabilization (EIS)
|
|
Smart Illumination
|
Yes
|
|
Defog
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Audio
|
|
Built-in Mic
|
Yes, built-in dual Mic
|
|
Built-in speaker
|
Yes, built-in speaker
|
|
Audio Compression
|
PCM; G.711a; G.711Mu; G.726; G.723
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; security exception
|
|
Network
|
|
Network
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
|
|
Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P
|
|
Interoperability
|
ONVIF (Profile S;Profile G;Profile T); CGI
|
|
User/Host
|
20 (Total bandwidth: 72 M)
|
|
Storage
|
FTP; SFTP; Micro SD card (support max. 256 G); NAS
|
|
Browser
|
IE: IE8/9/11
Chrome
Firefox
|
|
Management Software
|
SmartPSS Lite; DSS; DMSS
|
|
Mobile Phone
|
iOS; Android
|
|
Certification
|
|
Certification
|
CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
|
|
Port
|
|
Audio Input
|
1 channel (RCA port)
|
|
Audio Output
|
1 channel (RCA port)
|
|
Alarm Input
|
1 channel in: 5 mA 3V–5 VDC
|
|
Alarm Output
|
1 channel out: 300 mA 12 VDC
|
|
Power
|
|
Power Supply
|
12 VDC/PoE (802.3af)
|
|
Power Consumption
|
Basic: 3.3 W (12 VDC); 4.7 W (PoE)
Max. (H.265+main stream/IR intensity+warm light on): 7.7 W (12 VDC); 9 W (PoE)
|
|
Environment
|
|
Operating Conditions
|
–30 °C to +60 °C (–22 °F to +140 °F)/Less than 95% RH
|
|
Storage Conditions
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Protection Grade
|
IP67, IK10
|
|
Structure
|
|
Casing
|
Metal
|
|
Dimensions
|
105 mm × Φ126.0 mm (4.13" × Φ4.96" )
|
|
Net Weight
|
0.73 kg (1.61 lb)
|
|
Gross Weight
|
0.9 kg (1.98 lb)
|
