Camera
|
|
Image Sensor
|
1/2.8" CMOS
|
|
Max. Resolution
|
3840 (H) × 2160 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
1 GB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.007 lux@F1.5 (Color, 30 IRE)
0.0007 lux@F1.5 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
Up to 60 m (196.85 ft)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
4 (IR LED)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Motorized vari-focal
|
|
Lens Mount
|
φ14
|
|
Focal Length
|
2.7 mm–13.5 mm
|
|
Max. Aperture
|
F1.5
|
|
Field of View
|
Horizontal: 109°–30°
Vertical: 56° –17°
Diagonal: 131° –35°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
0.8 m (2.62 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
W
|
88.3 m
(289.70 ft)
|
35.3 m
(115.81 ft)
|
17.7 m
(58.07 ft)
|
8.8 m
(28.87 ft)
|
|
T
|
289.7 m
(950.46 ft)
|
115.7 m
(379.59 ft)
|
57.9m
(189.96 ft)
|
29.0 m
(95.14 ft)
|
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Tripwire, intrusion (support the classification and accurate detection of vehicle and human)
|
|
AI SSA
|
Yes
|
|
Quick Pick
|
With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events
|
|
Smart Search
|
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+
Smart H.264+
|
|
AI Coding
|
AI H.265
AI H.264
|
|
Video Frame Rate
|
Main stream: 3840 × 2160 @ (1–25/30) fps
Sub stream 1: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps)
Sub stream 2: 1920 × 1080 @ (1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
|
|
Stream Capability
|
3 streams
|
|
Resolution
|
8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 ×
1728/2592 × 1944); 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M(1280 × 960); 720p (1280 × 720); D1 (704 × 576/704×480); CIF (352 × 288/352 × 240); VGA (640 × 480)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
Scene Self-adaptation (SSA)
|
Yes
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Image Stabilization
|
Electronic Image Stabilization (EIS)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Defog
|
Yes
|
|
AFSA
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (support 90°/270° with 2688 × 1520 resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Audio Compression
|
G.711a; G.711Mu; PCM; G.726; G.723
|
|
Alarm
|
|
Alarm Event
|
-ZAS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; safety exception
-ZS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; SMD; safety exception
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Network Protocol
|
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P
|
|
Cyber Security
|
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
|
|
Interoperability
|
ONVIF (Profile S/Profile G/Profile T); CGI
|
|
User/Host
|
20 (Total bandwidth: 64 M)
|
|
Storage
|
FTP; SFTP; Micro SD card (support max. 256 G); NAS
|
|
Browser
|
IE: IE11
Chrome
Firefox
|
|
Management Software
|
SmartPSS Lite; DSS; DMSS
|
|
Mobile Client
|
IOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
|
|
Port
|
|
Audio Input
|
1 channel (RCA port) (Only - ZAS supports)
|
|
Audio Output
|
1 channel (RCA port) (Only - ZAS supports)
|
|
Alarm Input
|
1 channel in: wet contact, 5 mA 3 V–5 VDC (Only - ZAS supports)
|
|
Alarm Output
|
1 channel out: wet contact, 300 mA 12 VDC (Only - ZAS supports)
|
|
Power
|
|
Power Supply
|
12 VDC/PoE (802.3af)
|
|
Power Consumption
|
Basic: 4 W (12 VDC); 4.9 W (PoE)
Max. (WDR + IR intensity + Intelligence): 9.2 W (12 VDC); 10.5 W (PoE)
|
|
Environment
|
|
Operating Temperature
|
–30 °C to +60 °C (–22 °F to 140 °F) /Less than 95% RH
|
|
Storage Temperature
|
–40°C to +60°C (–40°F to 140°F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing
|
Metal
|
|
Product Dimensions
|
244.1 mm × 79.0 mm × 75.9 mm
(9.61" × 3.11" × 3.00") (L × W × H)
|
|
Net Weight
|
820 g (1.81 lb)
|
|
Gross Weight
|
1090 g (2.40 lb)
|
