Camera
|
|
Image Sensor
|
Dual 1/1.8" CMOS
|
|
Max. Resolution
|
4096 (H) × 1800 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
1 GB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.0005 lux@F1.0 (Color, 30 IRE)
0.0002 lux@F1.0 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
40 m (131.23 ft)
|
|
Illuminator On/Off Control
|
Auto
|
|
Illuminator Number
|
4 (Warm light)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M16
|
|
Focal Length
|
3.6 mm
|
|
Field of View
|
H: 180°±10°
V: 48°
|
|
Max. Aperture
|
F1.0
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
3.6 m (11.81 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
3.6 mm
|
70.3 m (230.64 ft)
|
28.1 m
(92.19 ft)
|
14.1 m
(46.26 ft)
|
7.0 m
(22.97 ft)
|
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
|
|
Heat Map
|
Yes
|
|
Smart Object Detection
|
Smart abandoned object; smart missing object
|
|
People Counting
|
Support the counting of enter number, leave number and pass number, and displaying and outputting yearly/monthly/daily reports.
Support the counting of number in area, and 4 rules configuration. Count number of people or stay time and link alarm.
Support queue management, and 4 rules configuration. Count number of people or stay time and link alarm
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
AI Coding
|
AI H.265; AI H.264
|
|
Video Frame Rate
|
WDR Off:
Main stream: 4096 × 1800 @ (1–25 fps)
sub stream: 1024 × 452 @ (1–25 fps)
third stream: 1920 × 832 @ (1–25 fps)
WDR On:
Main stream: 4096 × 1800 @ (1–20 fps)
sub stream: 1024 × 452 @ (1–20 fps)
third stream: 1920 × 832 @ (1–20 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Stream Capability
|
3 streams
|
|
Resolution
|
8M (4096 × 1800); 6.5M (3840 × 1680); 4M (3840 × 1080); 4M (2880 × 1264); 1.6M (1920 × 832); 0.7M (1280 × 560); 0.5M (1024 × 452)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 9 kbps–8192 kbps
H.265: 9 kbps–8192 kbps
|
|
Day/Night
|
Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
140 dB
|
|
Scene Self-adaptation (SSA)
|
Yes
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Privacy Masking
|
4 areas
|
|
Defog
|
Yes
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Audio Compression
|
G.711a; G.711Mu; PCM; G.726; G.723
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; SMD; people counting in area; stay detection; people counting; security exception
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
|
|
Network Protocol
|
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; Bonjour
|
|
Interoperability
|
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone
|
|
User/Host
|
20 (Total bandwidth: 80 M)
|
|
Storage
|
FTP; SFTP; Micro SD card (support max. 512 GB); NAS
|
|
Browser
|
IE: IE 11 and later
Chrome
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
|
|
Port
|
|
Audio Input
|
1 channel (RCA port)
|
|
Audio Output
|
1 channel (RCA port)
|
|
Alarm Input
|
1 channels in: 5 mA 3 V–5 VDC
|
|
Alarm Output
|
1 channel out: 300 mA 12 VDC
|
|
Power
|
|
Power Supply
|
12 VDC (±30%)/PoE+ (802.3at)/ePoE
|
|
Power Consumption
|
Basic: 4.8 W (12 VDC); 5.5 W (PoE)
Max. (WDR + intelligence + warm light + SPK): 12.3 W (12 VDC); 13.8 W (PoE)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
≤95%
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing
|
Metal + plastic
|
|
Product Dimensions
|
301.2 mm × 128.2 mm × 120.1 mm (11.86" × 5.05" × 4.73") (L × W × H)
|
|
Net Weight
|
1420 g (3.13 lb)
|
|
Gross Weight
|
1570 g (3.46 lb)
|
