NKB5200
NKB5200 - DAHUA - Clavier de contrôle avec Joystick - Compatible NVR & DSS - Contrôle PTZ 4 dimensions - Ecran LCD tactile 10" intégré
Model |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Model |
NKB5200(-F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
System |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor |
Embedded Processor |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operation System |
ANDROID 7.1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Output |
1-ch VGA or 1-ch HDMI(extension decoding display 720P resolution) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Stream Type |
H.265, H.264 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Capability |
1CH@4K(30fps)/4CH@1080P(30fps)/9CH@720P(30fps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Joystick |
4D joystick |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display split |
1/4/9 splits ,MxN splits |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen |
10.1" TFT LCD touch screen (1280*800) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio & Alarm |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio controller |
1 × volume button, 1 × mute button and touchscreen control |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Loudspeaker |
1 loudspeaker to play audio |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input |
1-ch 3.5 mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output |
1-ch 3.5 mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Speaker |
1 for audio play |
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Interface |
1×RJ-45 port (10/100/1000M), WLAN |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
USB Interface |
1 USB3.0, 2 USB2.0 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS485 |
1 for ptz control support PELCO |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Maximum Number of Users |
32 (including "admin") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max RS485 Addresses (Each User) |
8 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max Number of PTZ (IPC) That Can Be Added over Network (Each User) |
10000 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Access Protocol |
Dahua Private Protocol |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wifi |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless frequency range |
2.4Ghz 5Ghz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wireless transmission rate |
150Mbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environmental |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
12 VAC 4A max adapter,POE |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
< 48 W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working Temperature |
-10°C ~+55°C |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working Humidity |
10%~95% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimension |
Host: 425mmx194mmx59mm (W×D×H) (exclude joystick) Mini Keypad: 421mmx105mmx26mm (W×D×H) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross weight |
3.85kg(NKB5200 exclude package) 4.22kg(NKB5200-F exclude package) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net weight |
1.90kg(NKB5200 exclude package) 2.36kg(NKB5200-F exclude package) |
