Interface
|
|
Alarm In/Out
|
1/1
|
|
Door Control
|
1 Relay Out
1 RS485
1 Feedback
1 Exit Button
|
|
Wiegand In
|
1
|
|
Storage
|
Micro SD Card, Max 64 GB (reserved for software)
|
|
Network
|
|
Ethernet
|
10M/100Mbps
|
|
Network Protocol
|
TCP/IP
|
|
General
|
|
Ingress Protection
|
IK08, IP55 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
|
|
Tamper Switch
|
1
|
|
Installation
|
Surface & Flush
|
|
Material
|
Aluminum
|
|
Power
|
12 VDC, 2 A, PoE (802.3af)
|
|
Power Consumption
|
Standby ≤2W, Work ≤7W
|
|
Working Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Relative Humidity
|
20%–95% (RH)
|
|
Dimensions
|
200 mm × 98 mm × 32mm (7.87” × 3.86” × 1.26”)
|
|
Weight
|
1.5 kg (3.31 lb)
|
