Camera
|
|
Image Sensor
|
1/2.7" CMOS
|
|
Max. Resolution
|
3840 (H) × 2160 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
256 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100,000 s
|
|
Min. Illumination
|
0.009 lux@F2.0 (Color, 30 IRE)
0.0009 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
30 m (98.43 ft) (IR)
|
|
Illuminator On/Off Control
|
Auto; Manual
|
|
Illuminator Number
|
1 (IR LED)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm;3.6 mm
|
|
Max. Aperture
|
F2.0
|
|
Field of View
|
2.8 mm: H: 106°; V: 56°; D: 125°
3.6 mm: H: 88°; V: 46°; D: 104°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 1.3 m (4.27 ft)
3.6 mm: 1.9 m (6.23 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
88.0 m
(288.71 ft)
|
35.2 m
(115.49 ft)
|
17.6 m
(57.74 ft)
|
8.8 m
(28.87 ft)
|
|
3.6 mm
|
106.7 m
(350.07 ft)
|
42.7 m
(140.09 ft)
|
21.3 m
(69.88 ft)
|
10.7 m
(35.10 ft)
|
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
|
Intelligence
|
|
IVS (Perimeter Protection)
|
Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
|
|
Smart Search
|
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
Video Frame Rate
|
Main stream: 3840 × 2160@(1–20 fps)/2688 × 1520@(1–25/30 fps)
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Stream Capability
|
2 streams
|
|
Resolution
|
3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto; Manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Audio Compression
|
G.711a; G.711Mu; PCM; G.726
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Network Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour
|
|
Interoperability
|
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone
|
|
User/Host
|
20 (Total bandwidth: 48 M)
|
|
Storage
|
FTP; SFTP; Micro SD card (support max. 256 GB); NAS
|
|
Browser
|
IE
Chrome
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Client
|
iOS; Android
|
|
Cyber Security
|
Configuration encryption; Trusted execution; Digest; Security logs; WSSE; Account lockout; syslog; Video encryption; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Firmware encryption; Generation and importing of X.509 certification
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
|
|
Power
|
|
Power Supply
|
12 VDC/PoE (802.3af)
|
|
Power Consumption
|
Basic: 2.7 W (12 VDC); 3.4 W (PoE)
Max. (H.265+ max. resolution + max. stream+ WDR + IR intensity + IVS): 4.5 W (12 VDC); 5.4 W (PoE)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +55 °C (–40 °F to +131 °F)
|
|
Operating Humidity
|
≤95%
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Storage Humidity
|
≤95%
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing Material
|
Inner core: Metal
Cover: Metal
Decoration ring: Plastic
Quick install mounting plate: Metal
|
|
Product Dimensions
|
99.1 mm × Φ121.9 mm (3.90"× Φ4.80")
|
|
Net Weight
|
0.48 kg (1.06 lb)
|
|
Gross Weight
|
0.68 kg (1.50 lb)
|
