System
|
|
Main Processor
|
Industrial-grade processor
|
|
Operating System
|
Embedded Linux
|
|
Operating Interface
|
Web; Local GUI
|
|
Perimeter Protection
|
|
Perimeter Performance AI by Recorder (Number of Channels)
|
Advanced Model: 2 channels, 10 IVS for each channel
General Model: 8 channels, 10 IVS for each channel
|
|
Face Detection
|
|
Face Attributes
|
Gender; age group; glasses; expressions; face mask; beard
|
|
Face Detection Performance of AI by Recorder (Number of Channels)
|
2 channels (up to 12 face images/s each channel)
|
|
Face Recognition
|
|
Face Database Capacity
|
Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries & regions and state can be added to each face image
|
|
Face Recognition Performance of AI by Recorder (Number of Channels)
|
2 channels
|
|
SMD Plus
|
|
SMD Plus by Recorder
|
8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
|
|
Audio and Video
|
|
Analog Camera Input
|
8 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
|
|
Camera Input
|
1. CVI: 4K@25/30 fps; 6 MP@20 fps; 5 MP@20 fps; 5 MP@25 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps.
2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.
3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps
|
|
IP Camera Input
|
Up to 16 channels of IPC access
8 IP channels by default + 8 channels (analog channels are converted to IP channels)
incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps
*After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled
|
|
Encoding Capacity
|
Main stream: 4K@(1fps–15 fps); 6 MP@(1fps–20 fps); 5 MP, 4K-N,4 MP,3 MP, 1080p, 720p, 960H, D1, CIF@(1fps–25/30fps)
Sub stream: 960H@(1fps–15fps);D1,CIF@(1fps–25/30fps)
|
|
Dual-stream
|
Yes
|
|
Video Bit Rate
|
32 kbps–8192 kbps
|
|
Audio Sampling
|
8 kHz, 16 bit
|
|
Audio Bit Rate
|
64 kbps
|
|
Video Output
|
1 HDMI, 1 VGA
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
|
|
Multi-screen Display
|
When IP extension mode not enabled: 1/4/8/9
When IP extension mode enabled: 1/4/8/9/16
|
|
Third-party Camera Access
|
ONVIF; Panasonic; Sony; Axis; Arecont; Samsung
|
|
Compression Standard
|
|
Video Compression
|
AI Coding; Smart H.265+; H.265; Smart H.264+; H.264
|
|
Audio Compression
|
G.711a; G.711u; PCM
|
|
Network
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P
|
|
Mobile Phone Access
|
IOS; Android
|
|
Interoperability
|
ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK
|
|
Browser
|
Chrome, IE9 or later, Firefox
|
|
Network Mode
|
Single-address mode
|
|
Recording Playback
|
|
Record Mode
|
General, motion detection; intelligent; alarm; POS
|
|
Recording Playback
|
1/4/9
|
|
Backup Method
|
USB device and network
|
|
Playback Mode
|
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
|
|
Storage
|
|
Disk Group
|
Yes
|
|
Alarm
|
|
General Alarm
|
Motion detection; video loss; tampering; local alarm
|
|
Anomaly Alarm
|
No disk; storage error; disk full; camera offline; IP conflict; MAC conflict
|
|
Intelligent Alarm
|
Face detection; face recognition; perimeter protection
|
|
Alarm Linkage
|
Record; snapshot (panoramic); IPC external alarm output; access controller; voice prompt; buzzer; log; preset; email
|
|
Ports
|
|
Audio Input
|
4-channel RCA
8-channel BNC (Coaxial Audio)
|
|
Audio Output
|
1-channel RCA
|
|
Two-way Talk
|
Yes (share the same audio input with the first channel)
|
|
Alarm Input
|
8 channels
|
|
Alarm Output
|
3 channels
|
|
HDD Interface
|
2 SATA ports, up to 16TB capacity for each disk. The maximum HDD capacity varies with environment temperature.
|
|
RS-485
|
1 port, for PTZ control
|
|
USB
|
2 (1 front USB 2.0 port, 1 rear USB 3.0 port)
|
|
HDMI
|
1
|
|
VGA
|
1
|
|
Network Port
|
1 (10/100/1000 Mbps Ethernet port, RJ-45)
|
|
General
|
|
Power Supply
|
DC 12V, 5A
|
|
Power Consumption
|
<15 W (without HDD)
|
|
Net Weight
|
1.80 kg (3.97 lb)
|
|
Gross Weight
|
3.10 kg (6.84 lb)
|
|
Product Dimensions
|
375.0 mm × 287.0 mm × 53.0 mm (14.76'' × 11.30'' × 2.09'') (W × D × H)
|
|
Packaging Dimensions
|
433.0 mm × 141.0 mm × 366.0 mm (17.05'' × 5.56'' × 14.41'') (W × D × H)
|
|
Operating Temperature
|
–10 °C to +55 °C (14 °F to +131 °F)
|
|
Operating Humidity
|
10%–90% (RH)
|
|
Installation
|
Rack or desktop
|
|
Certifications
|
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
FCC: Part 15 Subpart B
|
