System
|
|
Main Processor
|
Industrial-grade processor
|
|
Operating System
|
Embedded Linux
|
|
Operating Interface
|
Web, Local GUI
|
|
AI
|
|
AI by Recorder
|
SMD Plus
|
|
AI by Camera
|
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
|
|
Perimeter Protection
|
|
Perimeter Performance of AI by Camera (Number of Channels)
|
4 channels
|
|
Face Detection
|
|
Face Attributes
|
Gender; age group; glasses; expressions; face mask; beard
|
|
Face Detection Performance of AI by Camera (Number of Channels)
|
4 channels
|
|
Face Recognition
|
|
Face Recognition Performance of AI by Camera (Number of Channels)
|
4 channels
|
|
SMD Plus
|
|
SMD Plus by Recorder
|
4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
|
|
SMD Plus by Camera
|
4 channels
|
|
Audio and Video
|
|
Access Channel
|
4 channels
|
|
Network Bandwidth
|
80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
|
|
Resolution
|
12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF
|
|
Decoding Capability
|
AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps AI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps
|
|
Video Output
|
1 HDMI, 1 VGA Simultaneous： HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous： HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
|
|
Multi-screen Display
|
Main Screen: 1/4 Sub Screen: 1/4
|
|
Third-party Camera Access
|
ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha
|
|
Compression Standard
|
|
Video Compression
|
Smart H.265+; H.265; Smart H.264+; H.264
|
|
Audio Compression
|
G.711a; G.711u; PCM; G726
|
|
Network
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)
|
|
Mobile Phone Access
|
iOS; Android
|
|
Interoperability
|
ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK
|
|
Browser
|
Chrome; IE; Safari; Edge; Firefox
|
|
Recording Playback
|
|
Multi-channel Playback
|
Up to 4 channels
|
|
Record Mode
|
General, motion detection; intelligent; alarm
|
|
Backup Method
|
USB device and network
|
|
Playback Mode
|
Instant playback, general playback, event playback, tag playback, smart playback
|
|
Alarm
|
|
General Alarm
|
Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm
|
|
Anomaly Alarm
|
Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception
|
|
Intelligent Alarm
|
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
|
|
Alarm Linkage
|
Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email
|
|
Port
|
|
Audio Input
|
1-channel RCA
|
|
Audio Output
|
1-channel RCA
|
|
Alarm Input
|
NA (2 channels is optional)
|
|
Alarm Output
|
NA (1-channel 12 V 1 A output is optional)
|
|
Disk Interface
|
1 SATA port. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
|
|
USB
|
2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
|
|
HDMI
|
1
|
|
VGA
|
1
|
|
Network Port
|
1 (10/100 Mbps Ethernet port, RJ-45)
|
|
General
|
|
Power Supply
|
12 VDC, 2 A
|
|
Power Consumption
|
Total output of NVR is <10 W(without HDD)
|
|
Net Weight
|
0.81 kg (1.79 lb)
|
|
Gross Weight
|
1.38 kg (3.04 lb)
|
|
Product Dimensions
|
260.0 mm × 232.5 mm × 47.6 mm(10.24" × 9.15" × 1.87") (W × D × H)
|
|
Packaging Dimensions
|
334 mm × 89 mm × 314 mm (13.15" × 3.50" × 12.36") (W × D × H)
|
|
Operating Temperature
|
–10 °C to +55 °C (14 °F to +131 °F)
|
|
Storage Temperature
|
–20 °C to +60 °C (–4 °F to +140 °F)
|
|
Operating Humidity
|
10%–93% (RH), non-condensing
|
|
Installation
|
Rack or desktop
|
|
Certifications
|
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014
|
