System
|
|
Main Processor
|
Industrial-grade processor
|
|
Operating System
|
Embedded Linux
|
|
Operating Interface
|
Web, Local GUI
|
|
AI
|
|
AI by Recorder
|
Face detection; face recognition; perimeter protection; SMD Plus
|
|
AI by Camera
|
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
|
|
AcuPick AI by Camera + Recorder
|
Max. 16-channel, 1 combined event per channel/s
|
|
Perimeter Protection
|
|
Perimeter Performance AI by Recorder (Number of Channels)
|
4 channels, 10 IVS rules for each channel
|
|
Perimeter Performance of AI by Camera (Number of Channels)
|
16 channels
|
|
Face Detection
|
|
Face Attributes
|
Gender; age group; glasses; expressions; face mask; beard
|
|
Face Detection Performance of AI by Recorder (Number of Channels)
|
2 channels (up to 12 face images/s each channel)
|
|
Face Detection Performance of AI by Camera (Number of Channels)
|
16 channels
|
|
Face Recognition
|
|
Face Database Capacity
|
Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
|
|
Face Recognition Performance of AI by Recorder (Number of Channels)
|
1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s
2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/s
|
|
Face Recognition Performance of AI by Camera (Number of Channels)
|
16 channels
|
|
SMD Plus
|
|
SMD Plus by Recorder
|
8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
|
|
SMD Plus by Camera
|
16 channels
|
|
Video Metadata
|
|
Metadata Performance of AI by Camera (Number of Channels)
|
8 channels
|
|
Human Attributes
|
Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella
|
|
Motor Vehicle Attributes
|
License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location.
|
|
Non-motor Vehicle Attributes
|
Vehicle model, vehicle color, number of persons, helmet.
|
|
Vehicle License Plate Comparison
|
|
ANPR by Camera (Number of Channels)
|
8 channels
|
|
License Plate Database Capacity
|
1. Create up to 20,000 plate numbers.
2. Blocklist and allowlist
|
|
Audio and Video
|
|
Access Channel
|
16
|
|
Network Bandwidth
|
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing
AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
|
|
Resolution
|
32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
|
|
Decoding Capability
|
AI disabled:
2-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps;
8-channel 8 MP@30 fps; 12-channel 5 MP@30 fps;
16-channel 4 MP@30 fps
AI enabled:
1-channel 32 MP@25 fps; 1-channel 24 MP@25 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 6-channel 8 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps
|
|
Video Output
|
2 VGA, 2 HDMI
VGA:1920 × 1080, 1280 × 1024, 1280 × 720
HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720Heterogeneous video source output for HDMI1 and HDMI2
Simultaneous video source output for VGA1 and HDMI1
Simultaneous video source output for VGA2 and HDMI2
|
|
Multi-screen Display
|
Main screen: 1/4/8/9/16
Sub screen: 1/4/8/9/16
|
|
Third-party Camera Access
|
ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Samsung
|
|
Compression Standard
|
|
Video Compression
|
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
|
|
Audio Compression
|
G.711a; G.711u; PCM; G726
|
|
Network
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI
|
|
Mobile Phone Access
|
iOS; Android
|
|
Interoperability
|
ONVIF 22.12 (Profile T; Profile S; Profile G); CGI; SDK
|
|
Browser
|
Chrome;IE;Safari;Edge;Firefox
|
|
Network Mode
|
Multi-address mode, load balance, fault tolerance and other network port binding modes
|
|
Recording Playback
|
|
Multi-channel Playback
|
Up to 16 channels
|
|
Record Mode
|
General, motion detection; intelligent; alarm; POS
|
|
Backup Method
|
USB device and network
|
|
Playback Mode
|
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
|
|
Storage
|
|
Disk Group
|
YES
|
|
Alarm
|
|
General Alarm
|
Motion detection; privacy masking; local alarm
|
|
Anomaly Alarm
|
Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan; cybersecurity exception
|
|
Intelligent Alarm
|
Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
|
|
Alarm Linkage
|
Record; snapshot (panoramic); local alarm output; IPC external alarm output; access controller; audio; buzzer; log, preset; email
|
|
Port
|
|
Audio Input
|
1-channel RCA
|
|
Audio Output
|
2-channel RCA
|
|
Alarm Input
|
16 channels
|
|
Alarm Output
|
6 channels (1-channel 12 V 1 A output)
|
|
HDD Interface
|
4 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
|
|
eSATA
|
1
|
|
RS-232
|
1
|
|
RS-485
|
1 (half-duplex serial communication)
|
|
USB
|
3(1 front USB 2.0 port, 2 rear USB 3.0 ports)
|
|
HDMI
|
2
|
|
VGA
|
2
|
|
Network Port
|
2 (10/100/1000 Mbps Ethernet port, RJ-45)
|
|
General
|
|
Power Supply
|
100–240 VAC, 50-60 Hz
|
|
Power Consumption
|
Total output of NVR is ≤ 13 W (without HDD)
|
|
Net Weight
|
4.74 kg (10.45 lb)
|
|
Gross Weight
|
6.11 kg (13.47 lb)
|
|
Product Dimensions
|
440.0 mm × 415.1 mm x 70.0 mm (17.32" × 16.34" × 2.76") (W ×D × H)
|
|
Packaging Dimensions
|
530.0 mm × 500.0 mm × 210.0 mm (20.87" × 19.69" × 8.27")(W × D × H)
|
|
Operating Temperature
|
–10 °C to +55 °C (14 °F to +131 °F)
|
|
Storage Temperature
|
–20 °C to +60 °C (–4 °F to +140 °F)
|
|
Operating Humidity
|
10%–93% (RH)
|
|
Installation
|
Rack or desktop
|
|
Certifications
|
FCC: 47 CFR FCC Part15, SubpartB, Class A
CE-EMC: EN 55032: 2015+A1: 2020; EN IEC 61000-3-2: 2019+A1: 2021; EN 61000-3-3: 2013+A1: 2019+A2: 2021; EN 55035: 2017+A11: 2020; EN 50130-4: 2011+A1: 2014
CE-LVD: EN 62368-1: 2014
|
