HAC-HUM3200A-0280P-S5

Camera

Image Sensor

2 MP CMOS

Max. Resolution

1920 (H) × 1080 (V)

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s

Min. Illumination

0.01 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)

S/N Ratio

>65 dB

Illumination Distance

10 m (32.81 ft)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

2 (IR light)

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Lens Mount

M12

Focal Length

2.8 mm

Max. Aperture

F2.0

Field of View

H: 105°; V: 58°; D: 118°

Iris Control

Fixed

Close Focus Distance

0.5 m (1.64 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

42.1 m (138.12 ft)

16.8 m (55.12 ft)

8.4 m

(27.56 ft)

4.2 m

(13.78 ft)

ABF

Yes

Video

Video Frame Rate

CVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps
AHD: PAL: 1080p@25 fps; NTSC: 1080p@30 fps
TVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps
CVBS: PAL: 960H; NTSC: 960H

Resolution

1080p (1920 × 1080)

Day/Night

Color/B/W

BLC

BLC; DWDR; HLC

WDR

DWDR

White Balance

Auto; Area white balance

Gain Control

Auto/Manual

Noise Reduction

2D NR

Illumination Mode

Smart IR

Mirror

Yes

Privacy Masking

Off/On (8 areas, rectangle)

Certification

Certifications

CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035;
FCC: 47 CFR FCC Part 15, Subpart B;

Port

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Power

Power Supply

12 VDC ± 30%

Power Consumption

Max 3.3 W (12 VDC, IR on)

Environment

Operating Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity

<95% (RH), non-condensing

Storage Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Storage Humidity

<95% (RH), non-condensing

Structure

Casing Material

Plastic

Product Dimensions

61.7 mm × 58.1 mm × 119.7 mm (2.43" × 2.29" × 4.71")

Net Weight

0.12 kg (0.26 lb)

Gross Weight

0.19 kg (0.42 lb)

Installation

Wall Mount
