System
|
|
Main Processor
|
Embedded Processor
|
|
Button Type
|
Mechanical
|
|
Interoperability
|
ONVIF; CGI
|
|
Network Protocol
|
RTSP; DNS; P2P; UPnP; RTP; RTMP; SIP; SSH; HTTP/HTTPS; ONVIF
|
|
Basic
|
|
Camera
|
1/2.8" CMOS 2-MP HD camera
|
|
Field of View
|
H: 110°; V: 62°; D: 133°
|
|
WDR
|
120 dB
|
|
Noise Reduction
|
3D NR; 2D NR
|
|
Video Compression
|
H.264; H.265
|
|
Video Resolution
|
Main stream: 720p, WVGA, D1, and CIF;
Sub stream: 1080p, WVGA, D1, QVGA, and CIF
|
|
Video Frame Rate
|
PAL: 25 fps
NTSC: 30 fps
|
|
Video Bit Rate
|
768 kbps–8 Mbps
|
|
Light Compensation
|
Auto IR
|
|
Day/Night
|
Auto (ICR)/Color/B/W; Color/B/W
|
|
Audio Compression
|
G.711a; G.711u; PCM
|
|
Audio Input
|
1
|
|
Audio Output
|
Built-in speaker
|
|
Audio Mode
|
Two-way audio
|
|
Audio Enhancement
|
Echo suppression/digital noise reduction; Echo suppression; Digital noise reduction
|
|
Audio Bit Rate
|
16 kHz, 16 bit
|
|
Function
|
|
Communication Mode
|
Full digital
|
|
Auto Snapshot
|
Yes (SD card is inserted in the indoor monitor or door station)
|
|
Leave Videos
|
Yes (SD card inserted in VTH/VTO is needed)
|
|
Web Configuration
|
Yes
|
|
Storage
|
Micro SD card (max. 256 GB)
|
|
Performance
|
|
Casing
|
PC + ABS
|
|
Port
|
|
Network Port
|
1 × RJ-45 10/100 Mbps Ethernet port
|
|
Exit Button
|
1
|
|
Door Status Detection
|
1
|
|
Lock Control
|
1
|
|
Alarm
|
|
Tamper Alarm
|
Yes
|
|
General
|
|
Appearance color
|
Light grey
|
|
Power Supply
|
12–33 VDC, 1 A ; Standard PoE
|
|
Power Adapter
|
Optional
|
|
Installation
|
Surface Mount
|
|
Certifications
|
CE
|
|
Accessory
|
Included: Alarm power ribbon cable, rain cover
|
|
Product Dimensions
|
160 mm × 50 mm × 30 mm (6.30" × 1.97" × 1.18")
|
|
Protection
|
IP65
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
10%–90% (RH), non-condensing
|
|
Operating Altitude
|
0 m–3,000 m (0 ft–9,842.51 ft)
|
|
Power Consumption
|
≤ 3.5 W (standby), ≤ 5.5 W (working)
|
|
Gross Weight
|
0.39 kg (0.86 lb)
|
|
Net Weight
|
0.17 kg (0.37 lb)
|
