Hardware
|
|
Included Power Adapter
|
Yes
|
|
PoE
|
Yes
|
|
Ethernet Port
|
16
|
|
Ethernet Port Speed
|
10/100 Mbps
|
|
Optical Port Speed
|
1000 Mbps
|
|
Ethernet Port Uplink Speed
|
10/100/1000 Mbps
|
|
Optical Port Uplink Speed
|
1 Gbps
|
|
Description of Function Slots
|
Port 1-16: 16 × RJ-45 10/100 Mbps (PoE); Port 17-18: 2 × RJ-45 10/100/1000 Mbps (combo); Port 17-18: 2 × SFP 1000 Mbps (combo)
|
|
Reset Button
|
1
|
|
Power Supply
|
Built-in power supply: 100-240 VDC, 47-63 Hz, max 4 A
|
|
Operating Temperature
|
–10 °C to +55 °C (+14 °F to +131 °F)
|
|
Operating Humidity
|
5%–95% (RH), non-condensing
|
|
Storage Temperature
|
–40 °C to +70 °C (–40 °F to +158 °F)
|
|
Storage Humidity
|
5%–95% (RH), non-condensing
|
|
Power Consumption
|
Idling: ≤6 W ; Full load: 212 W
|
|
Performance
|
|
Layer
|
Layer 2
|
|
Management Type
|
Yes
|
|
Smart Managed Switch
|
Yes
|
|
MTBF
|
87.10 years
|
|
Switching Capacity
|
7.2 Gbps
|
|
Packet Forwarding Rate
|
5.36 Mpps
|
|
Packet Buffer Size
|
4 Mbit
|
|
Jumbo Frame
|
15K Byte
|
|
MAC Table Size
|
8K
|
|
VLAN Number
|
32
|
|
Communication Standard
|
IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab; IEEE802.3z
|
|
Feature
|
|
PoE Protocol
|
IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
|
|
PoE Power
|
Port 1-2 ≤ 90 W, Port 3-16 ≤ 30 W, total ≤ 190 W
|
|
PoE Power Consumption Management
|
Yes
|
|
PoE Pin Assignment
|
1,2,4,5（V+）,3,6,7,8（V-）
|
|
Long Distance PoE Transmission
|
Yes
|
|
VLAN Function
|
Port-based VLAN
|
|
IEEE 802.3x Flow Control
|
Yes
|
|
DHCP Function
|
DHCP Client
|
|
Equipment Management
|
Web management; App management
|
|
General
|
|
Statics Protection
|
Air discharge: 8 kV; Contact discharge: 6 kV
|
|
Lighting Protection
|
Common mode: 4 kV; Differential mode: 2 kV
|
|
Net Weight
|
2.29 kg (5.04 lb)
|
|
Gross Weight
|
2.94 kg (6.47 lb)
|
|
Product Dimensions
|
440 mm × 220 mm × 44 mm (17.32" × 8.66" × 1.73") (L × W × H)
|
|
Packaging Dimensions
|
540 mm × 342 mm × 90 mm (21.26" × 13.46" × 3.54") (L × W × H)
|
|
Casing Material
|
Sheet metal
|
|
Installation
|
Desktop mount; rack mount
|
