PFS4210-8GT-150
- 8 Ports RJ-45 10/100/1000 Mbps PoE (Gigabit)
- 2 Ports SFP 1000 Mbps Uplink (fibre)
- Switch Manageable de niveau L2
- Switch Rackable
- Puissance max : 150W
Technical Specification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Model |
DH-PFS4210-8GT-150 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ethernet Port |
8*10/100/1000 Base-T (PoE power supply) 2*100/1000 Base-X |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS232 Serial Console |
1*RS232 in RJ45 connector with console cable, 115.2Kbps, 8,N,1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Power Consumption |
Each power ≤30W, Total≤150W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Protocol |
IEEE802.3af, IEEE802.3at |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Switching Capacity |
20Gbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packet Forwarding Rate |
14.88Mpps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packet Buffer Memory |
4Mb |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Application Humidity |
5%~95% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power |
AC100-240V, 50/60Hz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lightning Protection |
Common Mode 2KV Differential Mode 1KV |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working Temperature |
0°C~45°C |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimension(W×D×H) |
340mm x200mm x44mm |
Accessories |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Model |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PFT3950 |
1.25G 850nm,500m,LC, Multi-mode |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PFT3960 |
1.25G 1310/1550nm,20km,LC, Single-mode |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PFT3970 |
1.25G 1550/1310nm,20km,LC, Single-mode |
Service Characteristics |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
System |
Username / password: admin/admin |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IP Address :192.168.1.110/24 |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Budget |
Total≤150W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
MAC Table |
8K |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NTP |
Support |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DHCP |
Support DHCP client/server |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Support DHCP snooping |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VLAN |
802.1Q Standard VLAN |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port Aggregation |
Manual aggregation/LACP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirroring |
Many-to-one port mirroring |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Flow Control |
Half-duplex based on back pressure type control; Full duplex based on PAUSE frame |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multicast |
IGMP Snooping v1/v2/v3 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Security Features |
Users management, SSH, HTTPS, SNMP v1/v2/v3, ROMN, ACL, IP source guard, ARP inspection, 802.1x, loop protection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Spanning tree |
Support STP/RSTP/MSTP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
LLDP |
Support |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
MAC Table |
Support MAC address table configuration |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
QoS |
Support QoS base on CoS/DPL/PCP/DEI Each port support 8 output queue Support port shaping Support port tag remarking Support QoS base on DSCP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
System Maintenance |
Support the configuration file upload/download Support the updated packet upload System log |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Management |
WEB(http protocol), serial, SNMP |
Détails du produit
Fiche technique
- Marque
- DAHUA
- Nombre de ports PoE
- 8 Ports PoE
- Alimentation PoE
- Oui
- Management
- Manageable L2
- Nombre de ports RJ45
- 8 Ports RJ45
- Nombre de ports fibre
- 2 Ports SFP
- Budget PoE
- 150W
